Gasification Process

Gasification is a key step in pre-combustion carbon capture. This process converts carbon-based fuels, such as coal or biomass, into synthesis gas (syngas) - a mixture primarily composed of hydrogen, carbon monoxide, and carbon dioxide. The process typically occurs under high temperature and pressure conditions, with the fuel partially oxidized in the presence of steam and oxygen or air.


Water-Gas Shift Reaction

Following gasification, the syngas undergoes the water-gas shift (WGS) reaction. This critical step converts carbon monoxide and water vapor into hydrogen and carbon dioxide:

CO + H2O <=> CO2 + H2

The WGS reaction serves two important purposes:

1. It increases the concentration of CO2 in the gas stream, making it easier to capture.

2. It produces additional hydrogen, which can be used as a clean fuel source.

Carbon Dioxide Separation

After the WGS reaction, the gas mixture contains a high concentration of CO2 (typically 15-50%). This higher concentration and elevated pressure make CO2 separation more efficient compared to post-combustion capture methods.

Common separation techniques include:

• Physical absorption using solvents like Selexol or Rectisol

• Chemical absorption with amine-based solvents

• Membrane separation

• Adsorption using solid sorbents

Advantages of Pre-combustion Capture

1. Higher CO2 concentration:

The concentrated CO2 stream allows for more efficient capture.

2. Pressurized system:

The higher pressure of the gas stream reduces the energy required for CO2 compression.

3. Hydrogen production:

The process generates hydrogen, which can be used as a clean fuel.

Challenges and Ongoing Research

While pre-combustion capture offers several advantages, it also faces challenges:

1. High capital costs:

The gasification process can be more expensive than traditional pulverized coal plants.

2. Limited application:

Pre-combustion capture is primarily suitable for new plants or those designed for gasification.

3. Efficiency improvements:

Researchers are working on advanced solvents, sorbents, and membranes to reduce the energy penalty associated with carbon capture.

Emerging Technologies

Innovative approaches are being developed to enhance precombustion capture efficiency:

1. Sorption Enhanced Water Gas Shift (SEWGS):

This technology combines the WGS reaction with CO2 adsorption in a single step, potentially reducing energy requirements and equipment costs.

2. Chemical Looping:

This process uses metal oxides to transfer oxygen to the fuel, producing a pure stream of CO2 without the need for air separation.

3. Integrated gasification fuel cell (IGFC) systems:

These combine gasification with high-temperature fuel cells, potentially achieving higher efficiencies than traditional IGCC plants.

Pre-combustion carbon capture technologies offer a promising pathway for reducing CO2 emissions in power generation and industrial processes. As research continues and costs decrease, these technologies are likely to play an increasingly important role in global efforts to mitigate climate change.
